Front Panel Operations

To Set Source Output

NOTE The Limit (Compliance) value can be set to both positive and negative directions

individually by setting ON to the V/I Limit for Each Polarity field on the Display

Preference dialog box. See “Display Preference dialog box” on page 4-51.

To Set Output Range

For details on this function, see “Ranging Mode” on page 6-4 and “Range

parameters” on page 4-12.

1. Press the View key to display the Single view. If the Range parameters are not

displayed, press the Hide XXXX assist key.

2. Move the field pointer to the Source Volts: Spot (voltage source range) or

Source Amps: Spot (current source range) field.

3. Press the rotary knob to change the pointer status to EDIT.

4. Press AUTO to set the auto range operation or FIXED to set the fixed range

operation. The pointer status is changed to MOVE.

5. Move the field pointer to the range value setup field (on the right side of the

Source Volts: Spot or Source Amps: Spot field).

6. Press the rotary knob to change the pointer status to EDIT.

7. Press an assist key to set the following value.

For the auto range operation: Minimum range of the range operation

For the fixed range operation: Range used for source output

To Set Pulse Output

For details on this function, see “Pulse Output” on page 6-7.

1. Press the View key to display the Single view.

2. Press the Show Pulse assist key to display the Pulse parameters. For details on

the parameters, see “Pulse parameters” on page 4-16.

3. Move the field pointer to the Pulse field.

4. Press the rotary knob to change the pointer status to EDIT.

5. Press the ON assist key. The pointer status is changed to MOVE.

6. Move the field pointer to the pulse parameter setup field (Peak, Delay, or

Width).
