Keysight B2900 User’s Guide, Edition 5 6-41
Function Details
Initial Settings
Table 6-10 Calculate Functions Initial Settings
Setup item Power on Reset
Composite limit test result transfer
timing
IMM
Composite limit test result
automatic clearance
ON
Composite limit test fail bit pattern All 0
Composite limit test pass bit pattern All 0
Composite limit test mode GRADing
DIO pins for bit pattern output None
DIO pin for BUSY signal output None
DIO pin for EOT signal output None
DIO pin for SOT signal input None
Limit test feed source VOLTage
Compliance check fail bit pattern All 0
Compliance check fail condition IN
Limit test function LIM
Upper limit +1
Lower limit -1
Upper bit pattern All 0
Pass bit pattern All 0
Lower bit pattern All 0
Limit test enable OFF
Math function enable OFF
Math function expression (VOLT*CURR)
Math function expression name “POWER”
