1-2 Keysight B2900 User’s Guide, Edition 5
Getting Started
This chapter describes basic operations for Keysight B2900. Before learning the
details of B2900, let us briefly cover the use of the B2900 source/measure unit. The
operations require only B2900 and the power cord. To get started with the
operations, open the measurement terminals.
This chapter consists of the following sections.
• “Applying DC Output”
• “Performing Spot Measurement”
• “Performing Sweep Measurement”
• “Operation Tips”
• “Operation Summary”
NOTE Turning B2900 on
1. Connect the power cord from the AC input connector (receptacle) on B2900’s
rear panel to an AC power outlet at your site.
2. Press the standby switch on the front panel. When the power is on, the LED
below the switch is turned green.
B2900 boots up and performs a self-test. After B2900 boots normally, the front
panel LCD displays the following view. It will be the Single view for the 1-channel
model or the Dual view for the 2-channel model.
NOTE Connecting your DUT
If you want to connect your device under test, see “Connecting a DUT” on page
3-14.
D: Dual view
1: Single view
