Keysight B2900 User’s Guide, Edition 5 1-11
Getting Started
Operation Summary
Table 1-1 Basic Operations
Table 1-2 Channel Setup
Task Relevant front panel key
To turn the B2900 on/off Standby switch
To change the display mode
View key
To enable/disable the specified channel Ch 1
On/Off switch or Ch 2 On/Off switch
To cancel the previous setup operation
Cancel/Local key
To return to the upper menu of a function key or softkey
Cancel/Local key
To return to the local status from the remote status Cancel/Local key
To start a single (one shot) output/measurement
Trigger key
To start a repeat (continuous) measurement
Auto key
To move the field pointer Rotary knob or arrow keys
To move the digit pointer Rotary knob or arrow keys
To switch the EDIT/MOVE status Rotary knob on a setup field
To select the setup value Assist keys, rotary knob, or arrow keys
To save/recall all setup information of the B2900 Config > Save or Recall function keys
Task Relevant front panel key
To enable/disable the specified channel Ch 1
On/Off switch or Ch 2 On/Off switch
To select the sensing type; 2-wire or 4-wire Config > Source > Connection function keys
To select the low terminal status; grounded or floating Config > Source > Connection function keys
To enable/disable high capacitance mode Config > Source > Connection function keys
To enable/disable over voltage/current protection Config > Source > Connection function keys
To enable/disable resistance compensation Config > Measure > R Compen function keys
To enable/disable 2-channel synchronous operation Config > Common > Group function keys
