1-12 Keysight B2900 User’s Guide, Edition 5
Getting Started
Operation Summary
Table 1-3 Source Setup
Table 1-4 Measurement Setup
Task Relevant front panel key
To enable/disable source output Ch 1
On/Off switch or Ch 2 On/Off switch
To select source output mode Mode, Ch1 Mode, or Ch2 Mode assist key
To set source output value Source, Ch1 Source, or Ch2 Source assist key
To set limit/compliance value Limit, Ch1 Limit, or Ch2 Limit assist key
To set constant source ranging mode Speed assist key or Hide Sweep/Pulse/Trigger assist key on
Single view
To set sweep source Show Sweep assist key on Single view
To set list sweep source Edit assist key in the EDIT status for the LIST sweep
Start/Stop/Points field
To set sweep source ranging mode Config > Source > Sweep function keys
To set sweep direction Config > Source > Sweep function keys
To set source output value after sweep Config > Source > Sweep function keys
To set pulse source Show Pulse assist key on Single view
To set source wait time Config > Common > Wait function keys
To set output filter Config > Source > Filter function keys
To select output-off status Config > Source > Connection function keys
To enable/disable automatic output ON Config > Source > Connection function keys
To enable/disable automatic output OFF Config > Source > Connection function keys
Task Relevant front panel key
To enable/disable the specified channel Ch 1
On/Off switch or Ch 2 On/Off switch
To select measurement mode Measure, Ch1 Measure, or Ch2 Measure assist key
To set measurement speed Speed assist key on Single view
