From the remote interface:
Observe the following when creating or editing an Arb sequence:
l • The Arb function type (voltage or current) must match the Arb type specified in each sequence
step.
l • Sequence steps must be specified sequentially. The last value in the parameter list is the
sequence step number.
l • When a step type is added, all parameters must be entered.
To set up output 1 to program a voltage sequence:
ARB:FUNC:TYPE VOLT,(@1)
ARB:FUNC:SHAP SEQ,(@1)
ARB:SEQ:RESet (@1)
To program step 0 as the voltage pulse:
ARB:SEQ:STEP:FUNC:SHAP PULS,0,(@1)
ARB:SEQ:STEP:VOLT:PULS:STAR:TIM 0.25,0,(@1)
ARB:SEQ:STEP:VOLT:PULS:TOP 10.0,0,(@1)
ARB:SEQ:STEP:VOLT:PULS:TOP:TIM 0.5,0,(@1)
ARB:SEQ:STEP:VOLT:PULS:END:TIM 0.25,0,(@1)
The time of step 0 is the sum of the Start Time, Top Time and End Time. The default
pacing for sequence steps is Dwell-pacing.
3 Using the Source Functions
120 Keysight N6705C Operating and Service Guide
