AKD2G-S Installation, Safety 1 | 5 Package
5.1 Package Supplied
When a standard drive from the AKD2G series is delivered, the following items are included
in the drive package:
AKD2G
Printed copy of AKD
®
2G Product Safety Guide .
DVD with WorkBench setup software .
Panel safety label
Mating connectors are not included in the package of a standard drive.
Mating connectors are included when the drive is ordered with accessories (append “-A” to
the model number). With the accessories option all connectors to match the drive variant are
included, excepting SubD (Feedback 3), RJ25 (CAN bus) and RJ45 (service and fieldbus
networks).
Accessories Sold Separately
Accessories must be ordered separately if required.
EMC filters for mains supply voltage, categories C2 or C3.
External regen resistor.
Connector kits
Hybrid cable. Assembled hybrid motor cables are available for all regions.
Motor cable. Assembled motor cables are available for all regions.
Feedback cable. Assembled feedback cables are available for all regions.
SFA (Smart Feedback Adapter) .
SDB Module (Safe Dynamic Brake Module).
Ethernet service cable.
5.2 Nameplate
A nameplate is attached to the side of the drive. The picture below is similar to the nameplate
on the device.
28 Kollmorgen | kdn.kollmorgen.com | Beta, December 2018
