6.8.2.2 Technical data for AKD2G-Sxx-6V
Technical data for the regenerative circuit depends on the drive type and the mains voltage.
Supply voltages, capacitance, and switch-on voltages are all nominal values.
Brake circuit AC Supply
AKD2G-Sxx- Rated data Units 120V / 240V
6Vxxy
all types
Switch-on threshold of regenerative circuit V 380
Overvoltage limit V 420
Maximum regenerative duty cycle % 15*
AKD2G-Sxx- Rated data Units 120V / 240V
6V03S Internal regen resistor Ω 15
Continuous power, internal resistor W tbd
Peak brake power, internal resistor (0.5s) kW tbd
External regen resistor Ω 33
Continuous brake power, external resistor kW tbd
Peak brake power, external (1s) kW tbd
Absorption energy in capacitors (+/- 20%) Ws tbd / tbd
DC Bus Capacitance µF tbd
6V06S,
6V03D
Internal regen resistor Ω 15
Continuous power, internal resistor W tbd
Peak brake power, internal resistor (0.5s) kW tbd
External regen resistor Ω 33
Continuous brake power, external resistor kW tbd
Peak brake power, external resistor (1s) kW tbd
Absorption energy in capacitors (+/- 20%) Ws tbd / tbd
DC Bus Capacitance µF tbd
6V12S,
6V06D
Internal regen resistor Ω 15
Continuous power, internal resistor W tbd
Peak brake power, internal resistor (0.5s) kW tbd
External regen resistor Ω 33
Continuous brake power, external resistor kW tbd
Peak brake power, external resistor (1s) kW tbd
Absorption energy in capacitors (+/- 20%) Ws tbd / tbd
DC Bus Capacitance µF tbd
* depends on connected regen resistor power.
