8.9.3.1 Motor power and motor brake connectors X1, X2
Usually these lines are part of the Kollmorgen motor cable connected to X1 or X2. For motor
brake safety notes and functional details refer to (➜ # 82).
Use Kollmorgen cables
Mating connector data see (➜ # 51).
Cable length: maximum 50 m
Pin Signal Description
1 U Motor phase U
2 V Motor phase V
3 W Motor phase W
5 PE Protective earth
B+ BR+ Brake positive, with Kollmorgen cables only
B- BR- Brake negative, with Kollmorgen cables only
8.9.3.2 Feedback connectors X1, X2, X41, X21, X22, X23
Use Kollmorgen cables
Mating connector data see (➜ # 51).
Cable length: maximum 50 m
Connector Functionality Pinout, Wiring
X1/X2 SFD3, DSL, SFA (➜ # 85)
X41 SFA at X1 or X2 , several conventional feedback types (➜ # 89)
X21 Step/Direction, CW/CCW (➜ # 86)
X22 Step/Direction, CW/CCW, Incremental Encoder (➜ # 87)
X23 Several conventional feedback types (➜ # 88)
Feedback connector X1, X2, X41
Conventional feedback systems can be connected to X1 or X2 via the optional feedback
adapter SFA. SFA offers the additional connector X41.
Connector X1 is a standard connector. Input for SFD3, DSL, or SFA.
Connector X2 is standard for dual-axis drives. Input for SFD3, DSL, or SFA.
SFA: adapter for several conventional feedback types
Feedback connector X21
Connector X21 is a standard connector.
Input for Step/Direction and CW/CCW.
Feedback connector X22
Connector X22 is standard connector for dual-axis drives.
Connector X22 is part of option DX or IO for single axis drives.
Input for Step/Direction, CW/CCW, Incremental encoder
Feedback connector X23
Connector X23 is part of option DX or F3.
Input for several conventional feedback types.
AKD2G-S Installation, Safety 1 | 8 Electrical Installation
Kollmorgen | kdn.kollmorgen.com | Beta, December 2018 81
