6.5.2 Dual axis variants (D: I1=I2)
6.5.2.1 Mains supply data, 1 phase AC, type AKD2G-Sxx- (D)
Input data Units 6V03D 6V06D
Rated supply voltage (L1/N) VAC 1 x 100 V to 240 V
Rated supply input frequency Hz 50 Hz to 60 Hz ±5%
Permitted switch on/off frequency 1/h 30
Rated input power @ 240V kVA 2.38 2.64
Rated input current at 1 x 110 Vac A 9.9 11
Rated input current at 1 x 240 Vac A 9.9 11
Max. inrush current A 10
Rated DC bus link voltage VDC 310
6.5.2.2 Mains supply data, 3 phase AC, type AKD2G-Sxx- (D)
Input data Units 6V03D 6V06D 7V03D 7V06D
Rated supply voltage (L1/L2/L3) VAC 3 x 100 V to 240 V 3 x 200 V to 480 V
Rated supply input frequency Hz 50 Hz to 60 Hz ±5%
Permitted switch on/off frequency 1/h 30
Rated input power @ 240V (*480V) kVA 2.38 3.82 4.49* 7.65*
Rated input current at 3 x 110 Vac A 2.9 5.7 - -
Rated input current at 3 x 240 Vac A 5 5.7 5.4 9.2
Rated input current at 3 x 400 Vac A - - 5.4 9.2
Rated input current at 3 x 480 Vac A - - 5.4 9.2
Max. inrush current (at 240 V/480 V, 2C) A 10
Rated DC bus link voltage VDC 310 620
6.5.2.3 Auxiliary voltage input data, 24V DC, type AKD2G-Sxx- (D)
Input data Units 6V03D 6V06D 7V03D 7V06D
Aux. voltage supply (PELV) VDC 24 V (±10%, check voltage drop)
- current without motor brake A 1.25
- control current with one motor brake A 3.75
- control current with two motor brakes A 6.25
AKD2G-S Installation, Safety 1 | 6 Technical description and data
Kollmorgen | kdn.kollmorgen.com | Beta, December 2018 37
