2.3 Prohibited use
Other use than described in chapter 2.2 is not intended and can lead to damage of per
-
sons, equipment or things.
The use of the servo amplifier in the following environments is prohibited:
- potentially explosive areas
- environments with corrosive and/or electrically conductive acids, alkaline solutions,
oils, vapors, dusts
- directly on non-grounded supply networks or on asymmetrically grounded supplies
with a voltage >240V.
- on ships or off-shore applications
Commissioning the servo amplifier is prohibited if the machine in which it was installed,
- does not meet the requirements of the EC Machinery Directive
- does not comply with the EMC Directive or with the Low Voltage Directive
- does not comply with any national directives
The control of holding brakes by the S700 alone may not be used in applications, where
functional safety is to be ensured with the brake.
2.4 Handling
2.4.1 Transport
l
Transport by qualified personnel in the manufacturer’s original recyclable packaging
l
Avoid shocks while transporting
l
Transport temperature: -25 to +70°C, max. rate of change 20K / hour,
class 2K3 acc. to EN61800-2, EN 60721-3-1
l
Transport humidity: max. 95% relative humidity, no condensation,
class 2K3 acc. to EN61800-2, EN 60721-3-1
l
If the packaging is damaged, check the unit for visible damage. In such an event, in-
form the shipper and the manufacturer.
The servo amplifiers contain electrostatically sensitive components, that can be damaged
by incorrect handling. Discharge yourself before touching the servo amplifier. Avoid
contact with highly insulating materials, such as artificial fabrics and plastic films. Place
the servo amplifier on a conductive surface.
2.4.2 Packaging
l
Recyclable cardboard with inserts
l
Dimensions: S701...S712 (HxWxD) 125x415x350 mm
S724 (HxWxD) 155x415x350 mm
l
Labeling: name plate on outside of box
