Kollmorgen S700

8.3 Quickstart
8.3.1 Preparation
Unpacking, Mounting and Wiring the Servo Amplifier
1. Unpack servo amplifier and accessories
2. Observe safety instructions in the manuals
3. Mount the servo amplifier as described in chapter 6
4. Wire the servo amplifier as described in chapter 7 or apply the minimum wiring for drive
testing as described in chapter 8.3.1
5. Install the software as described in chapter 8.2
6. You need this information concerning the drive components:
- rated mains supply voltage
- motor type (motor data, if the motor type is not listed in the motor database,
see online help
- feedback unit built into the motor (type, poles, lines, protocol etc.)
- moment of inertia of the load
Documents
You need access to these documents (located on the product CD-ROM, you can
download the latest editions from our website):
l
Instruction manual (this manual)
l
CANopen Fieldbus Interface Manual
l
EtherCAT Fieldbus Interface Manual
l
Accessories manual
Depending on the installed expansion card you need one of these documents:
l
Operating Manual Safety Expansion Card Sx
l
PROFIBUS DP Fieldbus Interface Manual
l
DeviceNet Fieldbus Interface Manual
l
sercos
®
Fieldbus Interface Manual
You need Acrobat Reader to read the PDFs, an installation link is on every screen of the
product CD-ROM.
110 S701x2-S724x2 Instructions Manual
Setup 07/2014 Kollmorgen
