1 General
1.1 About this manual
This manual describes the S701x-S724x series of digital servo amplifiers (standard ver
-
sion: 1.5A ...24A rated current).
S7480x and S7720x amplifiers are described in an additional manuals.
A more detailed description of the expansion cards that are currently available and the
digital connection to automation systems can be found, together with our application
notes, in Acrobat-Reader format on the accompanying CD-ROM (system requirements:
WINDOWS, Internet Browser, Acrobat Reader) in different languages.
Technical data and dimensional drawings of accessories such as cables, brake resistors,
mains supplies, etc., can be found in the accessories manual.
This documentation (PDF) can be printed out on any standard commercial printer.
A printed copy of the documentation is available from us at extra cost.
More background information can be found in our "Product WIKI", available at
www.wiki-kollmorgen.eu
.
1.2
Notes for the printed edition (paper version)
A printed version of the manual is enclosed with each product.
For environmental reasons, the document was reduced in size
and printed on DIN A5.
Should you experience difficulties reading the font size of the
scaled-down printed version, you can print and use the PDF
version in DIN A4 format 1:1.
You can find the PDF version on the CD-ROM accompanying
the product and on the Kollmorgen website.
1.3 Notes for the online edition (PDF format)
Bookmarks:
Table of contents and index are active bookmarks.
Table of contents and index in the text:
The lines are active cross references. Click on the desired line and the appropriate page
is accessed.
Page numbers and chapter numbers in the text:
Page numbers and chapter numbers in the main text are active references. Click at the
page number or chapter number to reach the indicated target.
S701x2-S724x2 Instructions Manual 7
Kollmorgen 07/2014 General
