Kollmorgen S700

5.2 Technical data
5.2.1 Rated data S7xx0
Electrical data DIM S70102 S70302 S70602
S71202/
S7120S
S72402/
S7240S
Rated supply voltage
(grounded supply, phase to phase)
V~
3 x 208V
-10%
… 3 x 480V
+10%
, 50/60 Hz
Rated input power for cont. operation kVA 1.1 2.2 4.5 9 18
Permitted switch on/off frequency 1/h 30
Auxiliary voltage supply — ð p.30
Maximum DC bus link voltage V= 900
Rated output current (rms value, ± 3%)
at 3x208V Arms 2.5 5 6 12 24
at 3x230V Arms 2 4 6 12 24
at 3x400V Arms 1.5 3 6 12 24
at 3x480V Arms 1.5 3 6 12 24
Peak output current
(for approx.2s, ± 3%)
Arms 4,5 9 18 24/30 48/72
Peak output current
(for approx.5s, ± 3%)
Arms 3 6 12 24 48
Switching frequency of output stage kHz 8
Voltage rise speed dU/dt, (measured without connected motor, see hints on page 74!)
at 3x208V kV/µs 3.0
at 3x230V kV/µs 3.3
at 3x400V kV/µs 5.7
at 3x480V kV/µs 6.9
Technical data for brake circuit — ð p.34
Threshold for overvoltage switch-off VDC ð p.34
Motor inductance min.
at 3x208V mH 7.7 3.9 1.9 1.2 0.7
at 3x230V mH 8.5 4.3 2.1 1.3 0.8
at 3x400V mH 14.8 7.4 3.7 2.2 1.4
at 3x480V mH 17.8 8.9 4.4 2.7 1.7
Motor inductance max. mH Consult our customer support
Form factor of the output current (ra-
ted conditions, min. load inductance)
— 1.01
Bandwidth of current controller kHz > 1,2 (bis 5)
Residual voltage drop at rated current V 4 6
Thermal dissipation, output stage
disabled
W max. 20 max.25
Thermal dissipation at rated current
(incl. PSU losses, without brake
dissipation)
W 40 70 100 160 330
Noise emission max. dB(A) 43 43 58 65 65
Mechanical data
Weight kg 4.4 5.5
Height, without connectors mm 345 348
Height, with connectors mm 379 382
Width mm 70 100
Depth, without connectors mm 243 243
Depth, with connectors mm 285 285
28 S701x2-S724x2 Instructions Manual
Technical description 07/2014 Kollmorgen
