Kollmorgen S700

5.2.2 Rated data S7xx6
Electrical data DIM
S7016
2
S7036
2
S7066
2
S7126
2
S7126
S
S7246
2
S7246
S
Rated supply voltage
(grounded supply, phase to phase)
V~
1 x 110V
-10%
… 3 x 230V
+10%
, 50/60 Hz
Rated input power for cont. operation kVA 1 2 2,3 4,5 4,5 9 9
Permitted switch on/off frequency 1/h 30
Auxiliary voltage supply — ð p.30
Maximum DC bus link voltage V= 455
Rated output current (rms value, ± 3%)
at 1x110V (1~) Arms 1,5 36771010
at 1x230V (1~) Arms 1,5 36881111
at 3x110V (3~) Arms 2,5 5 6 12 12 24 24
at 3x230V (3~) Arms 2,5 5 6 12 12 24 24
Peak output current (rms value, ±3%)
at 1x110V (1~), for 2s / 5s Arms 3/3 3/3 6/6 7/7 7/7 10/10 10/10
at 1x230V (1~), for 2s / 5s Arms 4,5/3 9/6 12/12 12/12 12/12 13/13 13/13
at 3x110V (3~), for 2s / 5s Arms 4,5/3 9/6 18/12 24/24 30/24 48/48 72/48
at 3x230V (3~), for 2s / 5s Arms 4,5/3 9/6 18/12 24/24 30/24 48/48 72/48
Switching frequency of output stage kHz 8
Voltage rise speed dU/dt, (measured without connected motor)
at 1x110V kV/µs 2
at 1x230V kV/µs 3,3
at 3x110V kV/µs 2
at 3x230V kV/µs 3,3
Technical data for brake circuit — ð p.35
Threshold for overvoltage switch-off VDC ð p.35
Motor inductance min.
at 1x110V mH 5,7 5,7 2,9 2,5 2,5 1,7 1,7
at 1x230V mH 843332,82,8
at 3x110V mH 3,8 1,9 0,96 0,72 0,57 0,36 0,24
at 3x230V mH 8 4 2 1,5 1,2 0,75 0,5
Motor inductance max. mH Contact our customer support
Form factor of the output current (ra-
ted conditions, min. load inductance)
— 1.01
Bandwidth of current controller kHz > 1,2 (bis 5)
Residual voltage drop at rated current V 4 6
Thermal dissipation, output stage
disabled
W max. 20 max.25
Thermal dissipation at rated current
(incl. PSU losses, without brake
dissipation)
W 3045609090175175
Noise emission max. dB(A) 43 43 58 65 65 65 65
Mechanical data
Weight kg 4,4 5,5
Height, without connectors mm 345 348
Height, with connectors mm 379 382
Width mm 70 100
Depth, without connectors mm 243 243
Depth, with connectors mm 285 285
S701x2-S724x2 Instructions Manual 29
Kollmorgen 07/2014 Technical description
