5 Technical description
5.1 The S700 family of digital servo amplifiers
Standard version
l
Large supply voltage range: 1 x 110V
-10%
… 3 x 480V
+ 10%
l
Overvoltage category III acc. to IEC 61800-5-1
l
2 housing dimensions: S701...S712 70 mm
S724 100 mm
l
CANopen onboard
l
EtherCAT onboard
l
RS232 and 24V pulse direction interface onboard
l
Resolver-, Encoder-, AquadB Encoder-, ComCoder- evaluation onboard
l
Position controller onboard
l
Safe Stop STO onboard (up to SIL CL3, PLe)
l
3 frontside slots for expansion cards
l
Memory Card slot onboard
l
Synchronous servomotors, linear motors, asynchronous motors and DC motors can
be used
Power section
l
S7xx6: Directly on grounded mains supply, 1x110V
-10%
… 3x230V
+10%
, 50/60Hz
S7xx0: Directly on grounded mains supply, 3x208V
-10%
… 3x480V
+10%
, 50/60Hz
l
TN-network or TT-network with grounded neutral point, 42kA max. symmetrical cur-
rent rating, connection to other supply types only via isolating transformer,ðp.66
l
B6 bridge rectifier, integral supply filter and soft-start circuit
l
Fusing (e.g. fusible cutout) to be provided by the user
l
Shielding All shielding connections are made directly on the amplifier
l
Output stage IGBT module with floating current measurement
l
Brake circuit with dynamic distribution of the generated power between
several amplifiers on the same DC bus link circuit. Internal
brake resistor as standard, external brake resistors if required.
l
DC bus link voltage 135...900 V DC, can be connected in parallel.
l
Interference suppression filters are integrated for the electrical supply feed and the
24V auxiliary supply voltage (with motor cable £ 10m for C2 as per IEC 61800-3, with
motor cable > 10m for C3 as per IEC 61800-3).
S701x2-S724x2 Instructions Manual 25
Kollmorgen 07/2014 Technical description
