Korg PA1000 User Manual

114| SongBook
▪ Send the following string to select SongBook Entry #100:
Initialization string (CC#99, 98)
Thousands and hundreds (01xx)
Tens and units (xx00)
▪ Send the following string to select SongBook Entry #2563:
Initialization string (CC#99, 98)
Thousands and hundreds (25xx)
Tens and units (xx63)
Sending MIDI messages when selecting SongBook Entries
When the special Control channel is assigned to one of the MIDI OUT chan-
nels, MIDI messages are sent on this channel when choosing a SongBook
Entry. The messages sent when selecting a SongBook Entry are the follow-
ing:
▪ An initialization string, made of the NRPN Control Change messages #99
(MSB, with value 2) and #98 (LSB, with value 64) in fast succession.
▪ A selection string, made of the two Control Change messages CC#06 (Data
Entry MSB) for the thousands and hundreds, and CC#38 (Data Entry LSB)
for the tens and units. The range of the Data Entry controls, in this case, is
0~99 (instead of the typical 0~127).

Korg PA1000 Specifications

General

Sound Engine	EDS-X (Enhanced Definition Synthesis-eXpanded)
Polyphony	128 voices
Keyboard	61 keys with velocity and aftertouch
Display	7-inch TFT display
Song Player	MP3, SMF (Standard MIDI File), KAR
Storage	960 MB
Connectivity	USB, MIDI, Audio In/Out
Weight	10.75 kg (23.7 lbs)
Effects	148 effect types
Sounds	Over 1, 750 Factory Sounds, 107 Drum Kits
User PCM Sample Memory	600 MB
Style Tracks	8 tracks
Chord Sequencer	Yes
Pads	4 Assignable Pads
Lyrics	MID, KAR, MP3+Lyrics
Sequencer	16 tracks
SongBook	Fully programmable music database
Multi Pad	4 Assignable Pads
Connections	Audio In, Line Out
Clock	Internal
Power Supply	AC adapter
