Korg PA1000 User Manual

452| Customizing and editing the Sounds
36 Writing the Sounds
Writing the edited Sound
After editing, you can save all the edited parameters into a User Sound loca-
tion in memory.
Note: Changes can only be saved onto User Sounds.
1 While in Sound Edit mode, choose the Write Sound command from the page
menu to open the Write Sound dialog.
Sound name
Sound bank
Sound location
Touch to open
the Sound Select
window
2 You may change the name of the Sound. Touch the Text Edit ( ) icon to
open the virtual keyboard and edit the name.
When done editing the name, confirm by touching the OK button under the
virtual keyboard.
3 When back to the Write Sound dialog, if you want to save onto a different lo-
cation touch the Select button and open the Sound Select window. Choose
a location as if you were choosing a Sound. Blank locations are shown as a
series of dashes (‘–––’).
4 When back at the Write Sound dialog, confirm the Write operation by touch-
ing the OK button.
Some notes about writing the Sounds
▪ If you write over an existing Sound, the existing Sound will be deleted. Please
save on a storage device any User Sound you don’t want to lose.
▪ Ordinary Sounds cannot be written over Drum Kit locations. Drum Kits can-
not be written over standard Sound locations.

Korg PA1000 Specifications

General

Sound Engine	EDS-X (Enhanced Definition Synthesis-eXpanded)
Polyphony	128 voices
Keyboard	61 keys with velocity and aftertouch
Display	7-inch TFT display
Song Player	MP3, SMF (Standard MIDI File), KAR
Storage	960 MB
Connectivity	USB, MIDI, Audio In/Out
Weight	10.75 kg (23.7 lbs)
Effects	148 effect types
Sounds	Over 1, 750 Factory Sounds, 107 Drum Kits
User PCM Sample Memory	600 MB
Style Tracks	8 tracks
Chord Sequencer	Yes
Pads	4 Assignable Pads
Lyrics	MID, KAR, MP3+Lyrics
Sequencer	16 tracks
SongBook	Fully programmable music database
Multi Pad	4 Assignable Pads
Connections	Audio In, Line Out
Clock	Internal
Power Supply	AC adapter
