414| Customizing and editing the Sounds
Programming the pitch envelope (Pitch EG)
Pa1000 includes a pitch envelope generator (Pitch EG) that can vary the
pitch over time.
▪ Go to the Sound > Pitch > EG page.
You can see the shape of the envelope in the diagram on top of the page.
Setting the Pitch EG levels and times
Pitch EG can be programmed by setting the Level and Time parameters of
the envelope segments.
Note-on
Note-off
Attack
Time
Decay
Time
Start Level
Release Level
Release Time
Attack Level
+99 = approximately 1 octave
–99 = approximately 1 octave
0 = pitch when
key is held
(sustained)
Time
Time-varying pitch settings (when Pitch EG Intensity = +12.00)
▪ Use the Level parameters (-99…+99) to specify the amount of pitch change.
EG Level Meaning
Start Amount of pitch change at note start.
Attack Amount of pitch change when the attack time has elapsed.
Release Amount of pitch change when the release time has elapsed.
