Korg PA1000 User Manual

306| Customizing, recording and editing the Styles and Pads
Writing the Pads
Pads can be saved into a Pad memory location. After saving the Pads, assign
up to four of them to a Style or SongBook Entry, that will recall them.
1 While in Pad Record mode, choose the Write Pad command from the page
menu to open the Write Pad dialog.
Pad name
Pad bank
Pad location
Touch to open the
Pad Select window
2 You may change the name of the Pad. Touch the Text Edit ( ) icon to open
the virtual keyboard and edit the name.
When done editing the name, confirm by touching the OK button under the
virtual keyboard.
3 When back to the Write Pad dialog, if you want to save onto a different lo-
cation touch the Select button and open the Pad Select window. Choose
a location as if you were choosing a Style. Blank locations are shown as a
series of dashes (‘–––’).
4 When back at the Write Pad dialog, confirm the Write operation by touching
the OK button.

Korg PA1000 Specifications

General

Sound Engine	EDS-X (Enhanced Definition Synthesis-eXpanded)
Polyphony	128 voices
Keyboard	61 keys with velocity and aftertouch
Display	7-inch TFT display
Song Player	MP3, SMF (Standard MIDI File), KAR
Storage	960 MB
Connectivity	USB, MIDI, Audio In/Out
Weight	10.75 kg (23.7 lbs)
Effects	148 effect types
Sounds	Over 1, 750 Factory Sounds, 107 Drum Kits
User PCM Sample Memory	600 MB
Style Tracks	8 tracks
Chord Sequencer	Yes
Pads	4 Assignable Pads
Lyrics	MID, KAR, MP3+Lyrics
Sequencer	16 tracks
SongBook	Fully programmable music database
Multi Pad	4 Assignable Pads
Connections	Audio In, Line Out
Clock	Internal
Power Supply	AC adapter
