Korg PA1000 User Manual

Effect parameters |653
DYN (Dynamics)
Stereo Compressor
This effect compresses the input signal to regulate the level and give a
“punchy” effect. It is useful for guitar, piano, and drum sounds. This is a
stereo compressor. You can link left and right channels, or use each channel
separately.
Left
Right
FX Amt
FX Amt
Stereo In - Stereo Out
EQ Trim
EQ Trim
LEQ HEQ
LEQ
HEQ
Compressor
Compressor
Envelope Select
Output Level
Output Level
Envelope - Control
Envelope - Control
a Envelope Select L/R Mix,
L/R
Individually
Determines whether the left and right
channels are linked or used separately
b Sensitivity 1…100 Sets the sensitivity
c Attack 1…100 Sets the attack level
d EQ Trim 0…100 Sets the EQ input level
e Pre LEQ Fc Low,
Mid-Low
Selects the cutoff frequency (low or mid-
low) of the low-range equalizer
Pre HEQ Fc High,
Mid-High
Selects the cutoff frequency (high or
mid-high) of the high-range equalizer
f Pre LEQ Gain [dB] –15.0…+15.0 Sets the gain of the Low EQ
Pre HEQ Gain [dB] –15.0…+15.0 Sets the gain of the High EQ
g Output Level 0…100 Sets the output level of the compressor
Src Off…Tempo Selects the modulation source for the
compressor output level
Amt –100…+100 Sets the modulation amount for the com-
pressor output level

Korg PA1000 Specifications

General

Sound Engine	EDS-X (Enhanced Definition Synthesis-eXpanded)
Polyphony	128 voices
Keyboard	61 keys with velocity and aftertouch
Display	7-inch TFT display
Song Player	MP3, SMF (Standard MIDI File), KAR
Storage	960 MB
Connectivity	USB, MIDI, Audio In/Out
Weight	10.75 kg (23.7 lbs)
Effects	148 effect types
Sounds	Over 1, 750 Factory Sounds, 107 Drum Kits
User PCM Sample Memory	600 MB
Style Tracks	8 tracks
Chord Sequencer	Yes
Pads	4 Assignable Pads
Lyrics	MID, KAR, MP3+Lyrics
Sequencer	16 tracks
SongBook	Fully programmable music database
Multi Pad	4 Assignable Pads
Connections	Audio In, Line Out
Clock	Internal
Power Supply	AC adapter
