Korg PA1000 User Manual

216| Customizing, recording and editing the Styles and Pads
▪ To choose one of the available types of Pads, touch the buttons at the top
of the window.
Pad type Meaning
Hit While they are mostly used as non-transposing events, they can also
be transposing notes or chords. Basically, they are single-note or
single-chord Sequences (see below).
Sequence Single-track patterns, that can be transposed by playing different
chords on the keyboard – exactly as a Style track.
User Freely available locations to save your own Pads (created or edited
in Pad Record).
▪ To choose a different group of Pads, touch one of the tabs on the sides of
the window.
▪ To choose one of the available pages in the selected Pad group, touch one of
the P1…P6 tabs at the bottom of the window.
2 Touch the name of the Pad you want to choose.
3 If you want to close the Pad Select window (and it does not close by itself),
press the EXIT button. (When a window does not close by itself, it means the
Display Hold is turned on. See Display Hold on page 44).
4 Repeat the above procedure for the other Pads.
Memorize the assigned Pads
▪ Write the Style Settings.
Pads can also be memorized into a SongBook Entry. See the instructions
dedicated to the SongBook.

Korg PA1000 Specifications

General

Sound Engine	EDS-X (Enhanced Definition Synthesis-eXpanded)
Polyphony	128 voices
Keyboard	61 keys with velocity and aftertouch
Display	7-inch TFT display
Song Player	MP3, SMF (Standard MIDI File), KAR
Storage	960 MB
Connectivity	USB, MIDI, Audio In/Out
Weight	10.75 kg (23.7 lbs)
Effects	148 effect types
Sounds	Over 1, 750 Factory Sounds, 107 Drum Kits
User PCM Sample Memory	600 MB
Style Tracks	8 tracks
Chord Sequencer	Yes
Pads	4 Assignable Pads
Lyrics	MID, KAR, MP3+Lyrics
Sequencer	16 tracks
SongBook	Fully programmable music database
Multi Pad	4 Assignable Pads
Connections	Audio In, Line Out
Clock	Internal
Power Supply	AC adapter
