Korg PA1000 User Manual

Recording the Styles and Pads |259
Vel. Chord Type Vel. Chord Type
17 Diminished major 7th 18 Augmented
19 Augmented 7th 20 Augmented major 7th
21 Major w/o 3rd 22 Major w/o 3rd and 5th
23 Flatted 5th 24 Diminished 7th
As an example, a typical C Major progression will be entered as follows:
Chord Root Note Velocity
C Major C-1 1
A Minor A-1 8
D Minor D-1 8
G Dominant 7th G-1 13
C Major C-1 1
Selecting a Capo
A capo (from the Italian ‘capotasto’, ‘head of fingerboard’) is a movable bar
attached to the fingerboard of the guitar, to uniformly raise the pitch of all
the strings. Its use makes the strings shorter, therefore changing the timbre
and position of the chords (but not their shape).
This might prevent some strings to sound, depending on the chord position.
▪ Use the Capo > Fret pop-up menu to choose a Capo (‘capotasto’).
Capo Meaning
0 Open string – no capo.
I … XII Position of the capo over the fingerboard (i.e., “I” corresponds to the first
fret, “II” to the second one, and so on).
Selecting the lowest and highest strings
▪ Use the Strings > High/Low parameter pair to choose the highest and lowest
strings to play. This is like playing only some of the strings.
String Meaning
1 … 6 Selected string. The pattern will be played between these strings.

Korg PA1000 Specifications

General

Sound Engine	EDS-X (Enhanced Definition Synthesis-eXpanded)
Polyphony	128 voices
Keyboard	61 keys with velocity and aftertouch
Display	7-inch TFT display
Song Player	MP3, SMF (Standard MIDI File), KAR
Storage	960 MB
Connectivity	USB, MIDI, Audio In/Out
Weight	10.75 kg (23.7 lbs)
Effects	148 effect types
Sounds	Over 1, 750 Factory Sounds, 107 Drum Kits
User PCM Sample Memory	600 MB
Style Tracks	8 tracks
Chord Sequencer	Yes
Pads	4 Assignable Pads
Lyrics	MID, KAR, MP3+Lyrics
Sequencer	16 tracks
SongBook	Fully programmable music database
Multi Pad	4 Assignable Pads
Connections	Audio In, Line Out
Clock	Internal
Power Supply	AC adapter
