478| Customizing and editing the Sounds
Overview of the assigned samples and zones
You can see the overall map of the samples assigned to the zones, and edit
their range on the keyboard.
▪ Go to the Sampling > Multisample > Key Assign page.
Samples
Multisample
diagram
Zones
▪ Scroll the zones by using the list of samples on the left of the page. Use the
big button with an arrow on top and to the bottom of the list to scroll the list
up or down.
▪ Edit the zone range, when needed, by using the low and high zone limits
appearing on the left and the right of the keyboard diagrams. The Original
Note is shown in red.
