Korg PA1000 User Manual

608| Effects for the Sounds, Voice, Guitar
Black Chorus/Flanger
This models a Danish-made stereo chorus + pitch modulator & flanger.
Although this effect was originally intended for guitar, it was also used by
numerous keyboard players. Used with electric piano, it produces a distinc-
tive tone.
Left
Right
Wet / Dry
Wet / Dry
Wet: Mono In - Stereo Out / Dry: Stereo In - Stereo Out
+
Chorus
LFO
Input Gain
Mode & Intensity
Mono
Stereo
Output Mode
-
+
+
+
a Speed [Hz] 0.10…10.0 Sets the LFO speed
Src Off…Tempo Modulation for the LFO speed. See DMS
(Dynamic Modulation Source)
Amt –10.00…
+10.00
Sets the modulation amount of the LFO
speed
Intensity 1…100 Sets the intensity of LFO modulation
b Mode 0, 1, 2 Select a mode
0: Chorus
1: Pitch Modulation
2: Flanger
c Width 0…2 Sets the LFO modulation depth
d Input Gain 1…100 Sets the input gain
e Output Mode 0, 1 Select a output mode
0: Mono
1: Stereo
f Wet/Dry Dry, 1:99 … 99:1, Wet Balance between the wet and dry signal
Source Off…Tempo Selects a modulation source for Wet/Dry
Amount –100 … +100 Sets the modulation amount for Wet/Dry
a: Intensity
b: Mode
Increasing the “Intensity” value will strengthen the modulation effect. This
controls the effect, direct, and feedback values. The values that are con-
trolled will depend on the “Mode” setting.

Korg PA1000 Specifications

General

Sound Engine	EDS-X (Enhanced Definition Synthesis-eXpanded)
Polyphony	128 voices
Keyboard	61 keys with velocity and aftertouch
Display	7-inch TFT display
Song Player	MP3, SMF (Standard MIDI File), KAR
Storage	960 MB
Connectivity	USB, MIDI, Audio In/Out
Weight	10.75 kg (23.7 lbs)
Effects	148 effect types
Sounds	Over 1, 750 Factory Sounds, 107 Drum Kits
User PCM Sample Memory	600 MB
Style Tracks	8 tracks
Chord Sequencer	Yes
Pads	4 Assignable Pads
Lyrics	MID, KAR, MP3+Lyrics
Sequencer	16 tracks
SongBook	Fully programmable music database
Multi Pad	4 Assignable Pads
Connections	Audio In, Line Out
Clock	Internal
Power Supply	AC adapter
