Description Part No.
Item
No.
FIgure
No.
Recovery Tank Bracket 1009384-08 13 7-14
Red Light 31983 10 7-49
Reducing Elbow, 90° 1009384-02 7 7-15
Relay 1005908-08 3 7-16
Relay Mounting Bracket 36086 31 7-34
Relay, 12VDC, DSPT, 25A, N/O 985141 18 7-49
Relay, 12VDC, SPDT, 40A, 5-Pin 36085 32 7-34
Relay, 75A, SPST 20934592 30 7-34
Relief Valve Cartridge 1018059-02 24 7-21
Relief Valve Seal Kit 910065 REF 7-31
Remote Pot, Ultrasonic 982795 22 7-58
Replacement Key 35560 REF 7-24
Revolving Ball Knob, M12x1.75 981574 8 7-57
Revolving Ball Knob, M12x1.75 981574 7 7-65
Rheostat, 35 Ohm/25W 1010077 20 7-56
Rheostat, 35Ω/25W 1010077 29 7-41
Roll Pin, 1/4 x 1.25 400-4-20 20 7-8
Roll Pin, 3/16 x 2.25 400-3-36 51 7-8
Roll Pin, 3/8 x 2.00 400-6-32 13 7-5
Roll Up Curb Attachment, 12” (Left) 851635LSRV REF 7-70
Roll Up Curb Attachment, 12” (Right) 851635RSRV REF 7-70
Roll Up Curb Attachment, 24” (Left) 851636LSRV 3 7-70
Roll Up Curb Attachment, 24” (Right) 851636RSRV 4 7-70
Roller Chain, 40 x 52 Pitch 870190 12 7-37
Roller Chain, 40 x 52 Pitch 870190 2 7-46
Roller Chain, 60H x 39P w/Half-Link & Masterlink 1008047 19 7-52
Roller Chain, 60H x 51 Pitch 985815 27 7-8
Roller Chain, 80 x 56 Pitch 1019094 12 7-6
Roller Scraper Bracket, Large 1018312 11 7-3
Roller Scraper, Large 1018310 13 7-3
Roller Scraper, Small 1018311 12 7-3
Round Ball Knob, 3/8-16 x 1.375 851156 23 7-65
Round Knob, 1.375 x 3/8-16 851156 7 7-41
Round Knob, 1.375 x 3/8-16 851156 6 7-56
Round Tube 856854 11 7-74
Round Tube 856855 21 7-74
Round Tube Assembly 930040 REF 7-74
RTD Sensor, Bolt-On, 100Ω 1017394 12 7-68
Rubber Track Sprocket, Comer 1009464 20 7-2
