Description Part No.
Item
No.
FIgure
No.
Rubber Track/Undercarriage Assembly - Left 1009873 1b 7-2
Rubber Track/Undercarriage Assembly - Right 1009874 1a 7-2
Run Tee Adapter, -10 ORFS/-12 O-Ring/-10 ORFS FS6804-10-12-10-NWO-FG 16 7-22
Run Tee Adapter, -10 ORFS/-12 O-Ring/-10 ORFS FS6804-10-12-10-NWO-FG 16 7-23
Run Tee Adapter, -12 ORFS/ -16 O-Ring/ -12 ORFS FS6804-12-16-12-NWO-FG 5 7-20
Run Tee Adapter, -6 ORFS/-6 O-Ring/-6 ORFS FS6804-06-06-06-NWO-FG 12 7-12
Run Tee Bulkhead Adapter, -04 ORFS (x3) FS2704-04-04-04-FG 39 7-1
Run Tee Bulkhead Adapter, -04 ORFS (x3) FS2704-04-04-04-FG 37 7-2
Run Tee Bulkhead Adapter, -12 ORFS (x3) FS2704-12-12-12-FG 41 7-1
Run Tee Bulkhead Adapter, -12 ORFS (x3) FS2704-12-12-12-FG 39 7-2
Run Tee Bulkhead Adapter, -6 JIC / -6 JIC / -6 2704-6-6-6-LN 12 7-25
-S-
Safety Edge Depth Screw Bracket - Left 1011206 2a 7-67
Safety Edge Depth Screw Bracket - Right 1011205 2b 7-67
Safety Edge Spring Mechanism 1011453 13 7-67
Screed Arm Weldment, Adjustable - Left 1018713 1 7-41
Screed Arm Weldment, Adjustable - Left 1017801 1 7-56
Screed Arm Weldment, Adjustable - Right 1018714 2 7-41
Screed Arm Weldment, Adjustable - Right 1017802 2 7-56
Screed Base Elements Cover 985124 18 7-46
Screed Bulkhead Union Adapter 1015947 49 7-62
Screed Bulkhead Union Adapter 1015947 49 7-63
Screed Control Box - Left 1018750 25 7-41
Screed Control Box - Left 1018750 16 7-56
Screed Control Box - Right 1018749 26 7-41
Screed Control Box - Right 1018749 17 7-56
Screed Control Box Pivot 1008928SRV 13 7-41
Screed Control Box Pivot 1008928SRV 13 7-56
Screed Cover Weldment 1011697 29 7-51
Screed Cover, Extension Cylinder - Left 851204SRV 2 7-37
Screed Cover, Extension Cylinder - Right 851203SRV 3 7-37
Screed Extension Adjuster Assembly 851185SRV 3 7-47
Screed Extension Assembly - Left 1008079SRV REF 7-53
Screed Extension Assembly - Right 1008080SRV REF 7-54
Screed Extension Assembly, Electric - Left 985561SRV REF 7-47
Screed Extension Assembly, Electric - Right 985562SRV REF 7-47
Screed Extension Cylinder Cover - Left 851204SRV 33 7-46
Screed Extension Cylinder Cover - Right 851203SRV 34 7-46
Alphabetical Parts Index
LeeBoy 8510E Conveyor Paver7-220
