LeeBoy 8510E - Page 427

Description Part No.
Item
No.
FIgure
No.
Screed Extension Element Clamp 985123 6 7-47
Screed Extension Element Clamp 985123 9 7-53
Screed Extension Element Clamp 985123 9 7-54
Screed Extension Element Clamp 985123 32 7-62
Screed Extension Element Clamp 985123 32 7-63
Screed Extension Front Assembly - Left 1009634SRV 1 7-53
Screed Extension Front Assembly - Right 1009633SRV 1 7-54
Screed Extension Guard - Left 851180LSRV 1 7-38
Screed Extension Guard - Left 851180LSRV 1 7-47
Screed Extension Guard - Right 851180RSRV 2 7-38
Screed Extension Guard - Right 851180RSRV 2 7-47
Screed Extension Shaft - Chrome 988601 5 7-40
Screed Extension Toprail 855784 9 7-37
Screed Extension Toprail 855784 9 7-46
Screed Fiber Bushing Slide Assembly 1002186 1 7-40
Screed Front Pull Arm 851206 1 7-26
Screed Heat Box Assembly 987872SRV 4 7-47
Screed Heat Box Cover 988291SRV 5 7-47
Screed Heatbox Cover Assembly - Single Adjust 988291SRV 5 7-38
Screed Lift Cylinder, 2.50 x 12.00 x 1.00 1014284SRV 1 7-22
Screed Lift Cylinder, 2.50 x 12.00 x 1.00 1014284SRV 1 7-23
Screed Lock Harness 1019020 REF 7-34
Screed Pull Arm Pivot Ears 851210 6 7-26
Screed Pull Arm Pivot Mount 851209 13 7-26
Screed Thickness Adjuster Assembly 1011374SRV REF 7-57
Screed Vibrator Mount 854659 1 7-46
Screw, Self Drilling, HWH, #10 x 1.00 116-#10-16 20 7-10
Screw, Self Drilling, HWH, #10 x 1.00 116-#10-16 19 7-11
Screw, Self Drilling, HWH, #12 x .75 116-#12-12 5 7-44
Screw, Self Drilling, HWH, #12 x .75 116-#12-12 5 7-48
Screw, Self Drilling, HWH, #12 x .75 116-#12-12 6 7-60
Seal Kit for Item# 3 910170-01 - 7-22
Seal Kit for Item# 3 910170-01 - 7-23
Seal Kit, Track Tensioner Cylinder 811331-01 REF 7-1
Seal Kit, Track Tensioner Cylinder 811331-01 REF 7-2
Seal, Hydraulic Drive Motor 59941203 REF 7-1
Seal, Hydraulic Motor 59941203 REF 7-2
Seat Assembly, Short Post 1016967 REF 7-35
Seat Post Assembly - Short 988640SRV 2 7-35
7
Alphabetical Parts Index
LeeBoy 8510E Conveyor Paver 7-221
