June 2018
Legrand PDU User Guide 193
Event/context Default message when the event =
TRUE
Default message when the event
= FALSE
Inlet > Pole > * > Sensor >
Above upper critical threshold
Sensor '[PDUPOLESENSOR]' on pole
'[INLETPOLE]' of inlet '[INLET]'
asserted 'above upper critical' at
[SENSORREADING]
[SENSORREADINGUNIT].
Sensor '[PDUPOLESENSOR]' on
pole '[INLETPOLE]' of inlet '[INLET]'
deasserted 'above upper critical' at
[SENSORREADING]
[SENSORREADINGUNIT].
Inlet > Pole > * > Sensor >
Above upper warning threshold
Sensor '[PDUPOLESENSOR]' on pole
'[INLETPOLE]' of inlet '[INLET]'
asserted 'above upper warning' at
[SENSORREADING]
[SENSORREADINGUNIT].
Sensor '[PDUPOLESENSOR]' on
pole '[INLETPOLE]' of inlet '[INLET]'
deasserted 'above upper warning'
at [SENSORREADING]
[SENSORREADINGUNIT].
Inlet > Pole > * > Sensor >
Below lower warning threshold
Sensor '[PDUPOLESENSOR]' on pole
'[INLETPOLE]' of inlet '[INLET]'
asserted 'below lower warning' at
[SENSORREADING]
[SENSORREADINGUNIT].
Sensor '[PDUPOLESENSOR]' on
pole '[INLETPOLE]' of inlet '[INLET]'
deasserted 'below lower warning' at
[SENSORREADING]
[SENSORREADINGUNIT].
Inlet > Pole > * > Sensor >
Below lower critical threshold
Sensor '[PDUPOLESENSOR]' on pole
'[INLETPOLE]' of inlet '[INLET]'
asserted 'below lower critical' at
[SENSORREADING]
[SENSORREADINGUNIT].
Sensor '[PDUPOLESENSOR]' on
pole '[INLETPOLE]' of inlet '[INLET]'
deasserted 'below lower critical' at
[SENSORREADING]
[SENSORREADINGUNIT].
Inlet > Pole > * > Sensor >
Normal
Sensor '[PDUPOLESENSOR]' on pole
'[INLETPOLE]' of inlet '[INLET]'
entered normal state.
Sensor '[PDUPOLESENSOR]' on
pole '[INLETPOLE]' of inlet '[INLET]'
exited normal state.
Inlet > Pole > * > Sensor >
Failed
Sensor '[PDUPOLESENSOR]' on pole
'[INLETPOLE]' of inlet '[INLET]'
entered failed state.
Sensor '[PDUPOLESENSOR]' on
pole '[INLETPOLE]' of inlet '[INLET]'
exited failed state.
Inlet > Pole > * > Sensor >
Warning
Sensor '[PDUPOLESENSOR]' on pole
'[INLETPOLE]' of inlet '[INLET]'
entered warning state.
Sensor '[PDUPOLESENSOR]' on
pole '[INLETPOLE]' of inlet '[INLET]'
exited warning state.
Inlet > Pole > * > Sensor >
Critical
Sensor '[PDUPOLESENSOR]' on pole
'[INLETPOLE]' of inlet '[INLET]'
entered critical state.
Sensor '[PDUPOLESENSOR]' on
pole '[INLETPOLE]' of inlet '[INLET]'
exited critical state.
Inlet > Pole > * > Sensor >
Self-Test
Sensor '[PDUPOLESENSOR]' on pole
'[INLETPOLE]' of inlet '[INLET]' started
self test.
Sensor '[PDUPOLESENSOR]' on
pole '[INLETPOLE]' of inlet '[INLET]'
finished self test.
Outlet > * > Power control >
Powered on
Outlet '[OUTLET]' has been powered
on by user '[USERNAME]' from host
'[USERIP]'.
Outlet > * > Power control >
Powered off
Outlet '[OUTLET]' has been powered
off by user '[USERNAME]' from host
'[USERIP]'.
Outlet > * > Power control >
Power cycled
Outlet '[OUTLET]' power cycle initiated
by user '[USERNAME]' from host
'[USERIP]'.
Outlet > * > Sensor > Outlet
State > On/Off
Outlet '[OUTLET]' state changed to on. Outlet '[OUTLET]' state changed to
off.
Overcurrent Protector > * >
Sensor > * > Unavailable
Sensor '[OCPSENSOR]' on
overcurrent protector '[OCP]'
Sensor '[OCPSENSOR]' on
overcurrent protector '[OCP]'
