The top and bottom bars also turn yellow or red. See Operating the Dot-Matrix LCD Display (on
page 59).
Number Description
Sensor or actuator names.
Sensor or actuator states as listed below. For further information, see
Sensor/Actuator States (on page 121).
 n/a = unavail
able
 Norm
al
 Alarmed
 Lower Critical = below lower critical
 Lower Warning = below lower warning
 Upper Warning = above upper warning
 Upper Critical = above upper critical
 On
 Off
A numeric sensor shows both the reading and state. A state sensor or
actuator shows the state only.
