Chapter 2
| Using the Web Interface
Navigating the Web Browser Interface
– 57 –
Time Range Configures the time to apply an ACL or PoE port 387
Add Specifies the name of a time range 387
Show Shows the name of configured time ranges 387
Add Rule 387
Absolute Sets exact time or time range 387
Periodic Sets a recurrent time 387
LDB Loopback Detection 389
Configure Global Enables loopback detection globally, specifies the interval at which to
transmit control frames, specifies the interval to wait before releasing
an interface from shutdown state, specifies response to detect
loopback, and traps to send
390
Configure Interface Enables loopback detection per interface 392
Tools 431
Ping Sends ICMP echo request packets to another node on the network 431
Trace Route Shows the route packets take to the specified
destination
433
ARP Shows entries in the Address Resolution Protocol cache 434
Show Information Shows entries in the Address Resolution Protocol (ARP) cache 435
IP Service 437
DNS Domain Name Service 437
General 437
Configure Global Enables DNS lookup; defines the default domain name appended to
incomplete host names
438
Add Domain Name Defines a list of domain names that can
be appended to incomplete host names
438
Show Domain Names Shows the configured domain name list 438
Add Name Server Specifies IP address of name servers for dynamic lookup 440
Show Name Servers Shows the name server address list 440
Static Host Table 441
Add Configures static entries for domain name to address mapping 441
Show Shows the list of static mapping entries 441
Modify Modifies the static address mapped to the selected host name 441
Cache Displays cache entries discovered by designated
name servers
442
DHCP Dynamic Host Configuration Protocol 443
Client Specifies the DHCP client identifier for an interface 444
Relay Specifies DHCP relay servers 445
Table 4: Switch Main Menu (Continued)
Menu Description Page
