Repair information 4-199
7526
Go Back
Previous
Next
5. Install the waste toner HV contact assembly into place. Route the toner level sensor cables (E) through the
holes in the waste toner HV contact assembly while positioning the assembly. Make sure the aligner shaft
worm gear is aligned as shown.
E
Ribs aligned Rib
