Lexmark XM3150 Service Manual

Cooling fan service check
Action Yes No
Step 1
a Make sure that the cable JFAN1 is properly connected to the
controller board.
b Check if the cooling fan is rotating properly.
Is it rotating properly?
Go to step 2. Replace the cooling
fan. See
“Cooling
fan removal” on
page 281.
Step 2
a Turn o the printer, and disconnect JFAN1 from the controller
board.
b Turn on the printer, and measure the voltage across JFAN1.
Is the voltage approximately 24 V?
Go to step 3. Replace the
controller board. See
“Controller board
removal” on
page 282.
Step 3
Is the fan idle?
Replace the cooling
fan. See
“Cooling
fan removal” on
page 281.
The problem is
solved.
ACM service check
Action Yes No
Step 1
Check the pick/lift motor gearbox for proper operation.
a POR into the Diagnostics menu and perform a feed test:
Diagnostics Menu > Input Tray Tests > Feed Test > Tray 1
b Check if the pick/lift motor gearbox rotates on each pick.
Does it rotate during the feed test?
Go to step 2. Replace the pick/lift
motor gearbox. See
“Pick/lift motor
gearbox removal”
on page 338.
Step 2
Lower the ACM assembly, and rotate the pick roller toward the front
without touching the pick tire.
Does it rotate properly?
Replace the
controller board. See
“Controller board
removal” on
page 282.
Replace the ACM
assembly. See
“ACM
assembly removal”
on page 336.
Procedure before starting the 9yy service checks
You will need to retrieve certain information. This information will aid your next level of support in diagnosing
the problem before replacing the controller board.
Warning—Potential Damage: Do not replace the controller board unless directed by your next level of
support.
1 Collect the history information and firmware logs (Fwdebug and logs.tar.gz) from the SE menu.
2 Collect the settings from the menu settings page.
7016
Diagnostic information
144

Lexmark XM3150 Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	47 ppm
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	Scan
Digital sender	No
Maximum duty cycle	150000 pages per month
Recommended duty cycle	2000 - 15000 pages per month
Copier resize	25 - 400 %
Maximum copy resolution	- DPI
Copy speed (black, normal quality, A4)	47 cpm
Scan speed (black)	48 ppm
Scan speed (color)	32 ppm
Duplex scan speed (black)	21 ppm
Duplex scan speed (color)	14 ppm
Optical scanning resolution	600 x 1200 DPI
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Total input capacity	650 sheets
Total output capacity	250 sheets
Maximum input capacity	2300 sheets
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	7 3/4, 9, 10, DL
Maximum print size	216 x 356 mm
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Display	LCD
Control type	Touch
Product color	Grey, White
Display diagonal	7 \
Market positioning	Business
Direct printing	-
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Parallel, Serial (RS-422), Wireless LAN
Internal memory	1024 MB
Maximum internal memory	3072 MB
Sound pressure level (copying)	56 dB
Sound pressure level (printing)	55 dB
Power consumption (average operating)	- W
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	479 mm
Width	499 mm
Height	561 mm
Weight	23600 g
