Lexmark XM3150 Service Manual

Actions Yes No
Step 2
Make sure that the flatbed flat flexible cable is properly connected.
Does the problem remain?
Go to step 3. The problem is
solved.
Step 3
Check the flatbed flat flexible cable for damage, and then replace
the flatbed assembly if necessary. See
“Flatbed assembly
removal” on page 372.
Does the problem remain?
Go to step 4. The problem is
solved.
Step 4
Replace the controller board. See
“Controller board removal” on
page 282.
Does the problem remain?
Contact the next
level of support.
The problem is
solved.
ADF service check
Action Yes No
Step 1
Check all cables connecting the ADF and flatbed to the controller
board.
Are they properly connected?
Go to step 3. Go to step 2.
Step 2
Reconnect the cables to the controller board.
Did this fix the problem?
The problem is
solved.
Go to step 3.
Step 3
a Enter diagnostics mode and navigate to:
SCANNER TESTS > Sensor Test
Perform the scanner sensor tests.
b Navigate to:
SCANNER TESTS > Motor Tests
Perform the scanner sensor and motor tests.
Did any test fail?
Go to step 4. Go to step 8.
Step 4
Did the Flatbed Home Sensor test or Flatbed motor test fail?
Go step 5. Go to step 6.
7016
Diagnostic information
162

Lexmark XM3150 Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	47 ppm
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	Scan
Digital sender	No
Maximum duty cycle	150000 pages per month
Recommended duty cycle	2000 - 15000 pages per month
Copier resize	25 - 400 %
Maximum copy resolution	- DPI
Copy speed (black, normal quality, A4)	47 cpm
Scan speed (black)	48 ppm
Scan speed (color)	32 ppm
Duplex scan speed (black)	21 ppm
Duplex scan speed (color)	14 ppm
Optical scanning resolution	600 x 1200 DPI
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Total input capacity	650 sheets
Total output capacity	250 sheets
Maximum input capacity	2300 sheets
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	7 3/4, 9, 10, DL
Maximum print size	216 x 356 mm
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Display	LCD
Control type	Touch
Product color	Grey, White
Display diagonal	7 \
Market positioning	Business
Direct printing	-
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Parallel, Serial (RS-422), Wireless LAN
Internal memory	1024 MB
Maximum internal memory	3072 MB
Sound pressure level (copying)	56 dB
Sound pressure level (printing)	55 dB
Power consumption (average operating)	- W
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	479 mm
Width	499 mm
Height	561 mm
Weight	23600 g
