Lexmark XM3150 Service Manual

Action Yes No
Step 9
Does the error remain?
Contact the next
level of support.
The problem is
solved.
25y paper jams
25y paper jam messages
Error code Description Action
250.06 Input sensor did not detect sheet picked from
MPF. No other sheets should be in the path.
Go to
“MPF service check” on page 93.
250.10 Input sensor did not detect sheet picked from
MPF. No other sheets should be in the path.
Go to
“MPF service check” on page 93.
250.13 Input sensor did not detect sheet picked from
MPF. Sheet also last page of stapled job.
Go to
“MPF service check” on page 93.
250.14 Input sensor did not detect sheet picked from
MPF. Other sheets should have been flushed.
Go to
“MPF service check” on page 93.
250.17 Input sensor did not detect sheet picked from
MPF. No other sheets should be in the path.
Go to
“MPF service check” on page 93.
250.18 Input sensor did not detect sheet picked from
MPF. Other sheets could be in the path.
Go to
“MPF service check” on page 93.
MPF service check
Action Yes No
Step 1
Check the springs, links, and tray guides on the MPF assembly for
damage.
Are they free of damage?
Go to step 2. Replace the MPF
assembly. See
“MPF
tray removal” on
page 311.
Step 2
a Make sure the MPF sensor cable is properly connected to the
controller board.
b POR into the Diagnostics menu and perform a sensor test:
Diagnostics Menu > Input Tray Tests > Sensor Tests >
Multi‑Purpose Feeder
Does the sensor state on the control panel display change when
it is toggled?
Go to step 3. Replace the front
input guide. See
“Front input guide
removal” on
page 318.
7016
Diagnostic information
93

Lexmark XM3150 Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	47 ppm
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	Scan
Digital sender	No
Maximum duty cycle	150000 pages per month
Recommended duty cycle	2000 - 15000 pages per month
Copier resize	25 - 400 %
Maximum copy resolution	- DPI
Copy speed (black, normal quality, A4)	47 cpm
Scan speed (black)	48 ppm
Scan speed (color)	32 ppm
Duplex scan speed (black)	21 ppm
Duplex scan speed (color)	14 ppm
Optical scanning resolution	600 x 1200 DPI
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Total input capacity	650 sheets
Total output capacity	250 sheets
Maximum input capacity	2300 sheets
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	7 3/4, 9, 10, DL
Maximum print size	216 x 356 mm
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Display	LCD
Control type	Touch
Product color	Grey, White
Display diagonal	7 \
Market positioning	Business
Direct printing	-
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Parallel, Serial (RS-422), Wireless LAN
Internal memory	1024 MB
Maximum internal memory	3072 MB
Sound pressure level (copying)	56 dB
Sound pressure level (printing)	55 dB
Power consumption (average operating)	- W
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	479 mm
Width	499 mm
Height	561 mm
Weight	23600 g
