Lexmark XM3150 Service Manual

Assembly 2: Imaging
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 41X0917 1 1 ADF separator roller
“ADF separator roll removal ” on
page 359
2 40X9054 1 1 ADF input tray
“ADF input tray removal” on page 362
3 40X9093 1 1 ADF assembly
“ADF unit removal” on page 362
440X9110 1 1Restraint pad
“Restraint pad removal” on page 374
5 40X5804 1 1 Flatbed cushion (legal)
“Flatbed cushion removal ” on
page 360
6 40X7546 1 1 ADF right hinge
“ADF hinge removal” on page 371
7 40X9094 1 1 Flatbed
“Flatbed assembly removal” on
page 372
840X9051 1 1MPF USB cable
“USB cable removal” on page 369
9 40X9053 1 1 USB cable bracket
“USB cable bracket removal” on
page 304
10 40X9097 1 1 Scanner front cover
“Scanner front cover removal” on
page 361
11 40X9088 1 1 Cave light lens
“Cave light lens removal” on page 305
12 40X9080 1 1 Speaker cable
“Speaker cable removal” on page 372
13 40X9129 1 1 ADF left hinge
“ADF hinge removal” on page 371
14 40X9050 1 1 MPF wireless cable
“USB wireless cable removal” on
page 370
15 40X9079 1 1 Speaker
“Speaker removal” on page 304
16 40X8736 1 1 ADF pick roll N/A
17 40X9142 1 1 ADF top cover (legal)
“ADF top cover assembly removal” on
page 367
18 40X9117 1 1 High end ADF cable
“ADF cable removal” on page 368
7016
Parts catalog
448

Lexmark XM3150 Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	47 ppm
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	Scan
Digital sender	No
Maximum duty cycle	150000 pages per month
Recommended duty cycle	2000 - 15000 pages per month
Copier resize	25 - 400 %
Maximum copy resolution	- DPI
Copy speed (black, normal quality, A4)	47 cpm
Scan speed (black)	48 ppm
Scan speed (color)	32 ppm
Duplex scan speed (black)	21 ppm
Duplex scan speed (color)	14 ppm
Optical scanning resolution	600 x 1200 DPI
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Total input capacity	650 sheets
Total output capacity	250 sheets
Maximum input capacity	2300 sheets
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	7 3/4, 9, 10, DL
Maximum print size	216 x 356 mm
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Display	LCD
Control type	Touch
Product color	Grey, White
Display diagonal	7 \
Market positioning	Business
Direct printing	-
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Parallel, Serial (RS-422), Wireless LAN
Internal memory	1024 MB
Maximum internal memory	3072 MB
Sound pressure level (copying)	56 dB
Sound pressure level (printing)	55 dB
Power consumption (average operating)	- W
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	479 mm
Width	499 mm
Height	561 mm
Weight	23600 g
