19.21Resettingthesonar

Theresetfunctionrestorestheunittoitsfactory

defaultvalues.

Note:Performingafactoryresetwillclearspeed

andtemperaturecalibrationsettingsandthedepth

offset.

1.UsingacompatibleRaymarinemultifunction

displaygototheFishnderapplicationpage.

2.SelectMenufromthesidemenu.

3.SelectSet-up.

4.SelectSounderSet-up.

5.SelectSonarreset.

6.SelectYestoconrm.

Theunitwillnowberesettofactorydefaultsettings.
