4.18SeaTalk
ng
connections
ThedisplaycanconnecttoaSeaT alk
ng
network.
ThedisplaycanuseSeaTalk
ng
tocommunicatewith:
•SeaTalk
ng
instruments
•SeaTalk
ng
autopilots
•SeaTalkequipmentviatheoptionalSeaT alkto
SeaTalk
ng
converter
•NMEA2000equipmentviaoptionalDeviceNet
adaptorcables
TypicalSeaTalk
ng
system
00
D12176-4
12 V / 24 V dc
1
2
6
9
10
8
5
7
3
4
1.SeaT alk
ng
instrument
2.SeaT alk
ng
pilotcontrolhead
3.iTC-5converter
4.Windtransducer
5.SeaT alk
ng
multifunctiondisplay
6.Powersupply
7.SeaT alk
ng
autopilot
8.iTC-5converter
9.Depthtransducer
10.Speedtransducer
FordetailsofSeaTalk
ng
cablingpleasereferto
Chapter33Sparesandaccessories.
SeaTalk
ng
powerrequirements
TheSeaTalk
ng
busrequiresa12Vpowersupply.
Powermaybeprovidedfrom:
•Raymarineequipmentwitharegulated12Vpower
supply(forexample,aSmartPilotSPXcourse
computer);or:
•Othersuitable12Vpowersupply.
Note:SeaT alk
ng
doesNOTsupplypowerto
multifunctiondisplaysandotherequipmentwitha
dedicatedpowersupplyinput.
Cablesandconnections
