Lighthouse a65 - GPS Connection

Networkconnection
D12740-1
6
5
1
2
6
3 4
1.Networkswitch.
2.Fusionsystem.
3.RayNettoSeaT alk
hs
cable.
4.Fusionethernetconnector.
5.SecondFusionsystem(themultifunction
displaycanbeconnectedtomultipleFusion
entertainmentsystems).
6.Networkedmultifunctiondisplays.
Note:TheFusionentertainmentsystemcan
becontrolledbyanycompatiblenetworked
multifunctiondisplaywhenconnectedusinga
networkswitch.
4.14GPSconnection
Dependingondisplayvariant,yourmultifunction
displaymayincludeaninternalGPSreceiver.If
requiredthemultifunctiondisplaycanalsobe
connectedtoanexternalGPSreceiver,using
SeaTalk
ng
orNMEA0183.
GPSconnection—SeaTalk
ng
D12261-1
SeaTalk
ng
1
2
1.Multifunctiondisplay.
2.SeaT alk
ng
GPSreceiver.
GPSconnection—NMEA0183
D12262-1
NMEA 0183
1 2
1.Multifunctiondisplay.
2.NMEA0183GPSreceiver.
