4.12Weatherreceiverconnection
YoucanconnectaSiriusXMweatherreceiverto
yourmultifunctiondisplay.
RayNet
0
0
0
0
0
0
AUDIO
0
0
0
ANTENNA
0
NETWORK
0
0
POWER
0
0
D12902-2
1
2
1.Raymarineweatherreceiver.
2.Multifunctiondisplay.
Theweatherreceivercanalsobeconnectedtoa
Raymarinenetworkswitch.
ForinformationonconnectinganSR50using
SeaTalk
ng
pleasereferto82257–SR50operation
whichcanbedownloadedfromtheRaymarine
website:www.raymarine.com.
4.13Fusionlinkconnection
YoucanconnectaFusion700seriesmarine
entertainmentsystemtoyourmultifunctiondisplay.
Directconnection
1
2
3 4
D12741-1
1.Multifunctiondisplay.
2.Fusionsystem.
3.RayNettoSeaT alk
hs
cable.
4.Fusionethernetconnector.
Directconnectionwithnetworkedmultifunction
displays
3 2
D12742-1
4
1
5
1.Fusionsystem.
2.Fusionethernetconnector.
3.RayNettoSeaT alk
hs
cable.
4.Directlyconnectedmultifunctiondisplay.
5.Networkedmultifunctiondisplays.
Note:TheFusionentertainmentsystemcanbe
controlledbyadirectlyconnectedmultifunction
displayorbyanetworkedmultifunctiondisplay.
Cablesandconnections67
