4.16AISconnection
AcompatibleAIScanbeconnectedusingSeaTalk
ng
orNMEA0183.
ConnectionusingSeaTalk
ng
D12263-1
SeaTalk
ng
2
1
1.Multifunctiondisplay.
2.SeaT alk
ng
AISreceiver/transceiver.
ConnectionusingNMEA0183
NMEA0183 (38400)
NMEA 0183 (4800)
3
1
2
D12264-1
1.VHFradio.
2.AISunit.
3.Multifunctiondisplay.
4.17Fastheadingconnection
IfyouwishtouseMARPA(radartargetacquisition)
functionsonyourmultifunctiondisplayyouneed
either:
•Anautopilotconnectedtothemultifunctiondisplay
viaSeaTalk
ng
orNMEA0183.Thecompassis
connectedtothecoursecomputerandcalibrated
viathepilotcontrolhead;or:
•ARaymarineorthird-partyfastheadingsensor
connectedtothemultifunctiondisplayviaNMEA
0183.
Note:PleasecontactyourdealerorRaymarine
technicalsupportformoreinformation.
70aSeries/cSeries/eSeries
