4.22a6xanda7xtoNMEA0183DSC
VHFradioconnection
Toconnectana6xanda7xvariantMFDstoan
NMEA0183DSCradioaSeaTalk
ng
toNMEA0183
convertermustbeusedtoconverttheSeaTalk
ng
messagestoNMEA0183messages.
TheMFDandconvertermustbeconnectedtothe
sameSeaTalk
ng
backbone.
12 V dc
+
— —
+
43 5
2
8
11
D12833-1
10
1
SeaTalk
ng
12 V dc*
12 V dc
NMEA 0183 **
6 7
9
1
a6x/a7xMFD
2
SeaTalk
ng
spurcable
3
SeaTalk
ng
toNMEA0183barewiresspurcable
4
ConverterNMEA0183negativeconnection(yellow
wire)
5
NMEA0183deviceinputnegativeconnection(purple
wire)
6
ConverterNMEA0183positiveconnection(redwire)
7
NMEA0183deviceinputpositiveconnection(grey
wire)
8
NMEA0183DSCVHFRadio
9
SeaTalk
ng
powercable(onlyrequiredifnotconnecting
toanexistingpoweredSeaTalk
ng
backbone.
10
Converter
11
NMEA0183connection(usecablesuppliedwithVHF
radio)
Note:TheconnectionattheVHFradiomustbeto
theNMEA0183inputonly.Itisauni-directional
(one-way)connection.
4.23Camera/Videoconnection
Acameraoravideodevicecanbeconnecteddirectly
toNewcSeriesandNeweSeriesmultifunction
displaysusingthevideoconnectoronthepowerand
datacable.
Note:Videodevicescannotbedirectlyconnected
toNewaSeriesmultifunctiondisplays.Forcamera
connectionstoaNewaSeriesdisplaypleaserefer
totheIPcameraconnectionsection.
Examplesofvideosourcesthatyoucanconnectto
thedisplayinclude:
•Videocamera.
•Thermalcamera.
•DVDplayer.
•Portabledigitalvideoplayer.
D12178-2
1
2
4
3
1.Rearconnectorpanelofmultifunctiondisplay.
2.Poweranddatacable.
3.BNCvideoconnector(input1).
4.Videosource—forexample,videocamera.
Note:Tolistentoamovie’saudiotrack,any
connectedDVDordigitalvideoplayerwillrequire
speakerstobeconnectedtotheplayersaudio
output.
