4.19NMEA2000connection
ThedisplaycanreceivedatafromNMEA2000
devices(e.g.datafromcompatibleengines).The
NMEA2000connectionismadeusingSeaT alk
ng
andappropriateadaptorcables.
YoucanEITHER:
•UseyourSeaTalk
ng
backboneandconnecteach
NMEA2000deviceonaspur,OR
•connectthedisplayonaspurintoanexisting
NMEA2000backbone.
Important:Youcannothave2backbones
connectedtogether.
ConnectingNMEA2000equipmenttothe
SeaTalk
ng
backbone
NMEA 200012V
D12174-2
1
2
4
3
SeaTalk
ng
1.12Vsupplyintobackbone.
2.SeaT alk
ng
backbone.
3.SeaT alk
ng
toDeviceNetadaptorcable.
4.NMEA2000equipment.
ConnectingthedisplaytoanexistingNMEA2000
(DeviceNet)backbone
D12175-2
32
4
1
1.Multifunctiondisplay.
2.SeaT alk
ng
toDeviceNetadaptorcable.
3.DeviceNetbackbone.
4.NMEA2000equipment.
4.20SeaTalkconnection
YoucanconnectSeaTalkdevicestoyour
multifunctiondisplayusingtheoptionalSeaTalkto
SeaTalk
ng
converter.
D12265-1
SeaTalk
ng
SeaTalk
1
2
SeaTalk
ng
3
1.SeaT alkdevice.
2.SeaT alktoSeaTalk
ng
converter.
3.Multifunctiondisplay.
