Lighthouse a65 - Data Application Overview

21.1Dataapplicationoverview
TheDataapplicationenablesyoutoviewdata
generatedbythemultifunctiondisplayordatathatis
availableonyoursystem.
Datacanbeobtainedfromdevicesconnectedusing
SeaTalk
hs
,SeaTalk
ng
orNMEAprotocols.
Pre-congureddatapages
Thedefaultdatapagecongurationisdependant
upontheboattypeselectedduringtheinitialset-up
wizard.
Eachdatapageconsistsofanumberof'cells',that
displaytheinformation.
Defaultdatapagecongurationisshownbelow:
MotorvesselSailingvessel
Page
number
PagePage
number
Page
1/6
Engine
1/5
Engine
2/6
Navigation
2/5
Navigation
3/6
Environment
3/5Sailing
4/6
Fishing
4/5
Environment
5/6
Fuel
5/5
Rollingroad
6/6
Rollingroad
Note:Datapageselectionisalocalsetting,and
thereforeonlyaffectstheindividualdisplaythat
youarecurrentlyusing.Itdoesnotaffectany
networkeddisplays.
Enginepage
TheEnginepageisavailableforallboattypes.The
dialsandtypeofdatadisplayedisdependentonthe
NumberofenginessetintheBoatDetailssettings.
Important:Therelevantenginedatamustbe
availableonyournetworkfortheEnginepageto
showenginedata.
Example—enginepagefor2enginevessel.
D13058-1
5
7
6
1 42 3
8 9 10 11 12
1.Portenginecombinedoilpressureandcoolant
temperaturedial
2.T otalfuel
3.EngineEconomytotal
4.Starboardenginecombinedoilpressureand
coolanttemperaturedial
5.PortengineRPMdial
6.StarboardengineRPMdial
7.Trimtabs
8.SOG
9.Portalternator
10.Rudderbar
11.Starboardalternator
12.Depth
Navigationpage
TheNavigationpageisavailableforallboattypes.
D13062-1
5
6
7
8
1 42
3
10 119
1.Heading
2.Rollingroad
3.T argetwaypoint
4.WaypointETA(Estimatedtimeofarrival)
5.Headingtotargetwaypoint
6.Distancetotargetwaypoint
7.COG
8.SOG
9.VMGtowaypoint
10.Rudderbar
11.Depth
322aSeries/cSeries/eSeries
