Lighthouse a65 - Radar Display Overview

2.SelectPowerupRadartoturntheradaron,or
PowerdownRadartoturntheradaroff.
3.SelectRadar:Txtostarttheradartransmitting,
orRadar:Stdbytostoptheradartransmitting.
20.3Radardisplayoverview
Withyourradarscannerconnectedandtheradarin
transmitmode,theradarpictureprovidesamap-like
representationoftheareainwhichtheradaris
operating.
D12207-2
10 13 1411
1 3 5 6 7 98
2
4
15
12
ItemDescription
1Range
2
On-screencontrols(Touchscreen
multifunctiondisplaysonly.)
3
Gainmode
4
Ship'sHeadingMarker(SHM)
5
Orientation
6
GuardZone
7
Motionmode
8Rangestatus
9Rangeringspacing
10Datacelloverlay
11Waypoint
12
Safezonering
13
Rangeout(Touchscreenmultifunction
displaysonly.)
14
Rangein(Touchscreenmultifunctiondisplays
only.)
15
Ship'sposition
Note:On-screenrangecontrolscanbeenabled
anddisabledfromthehomescreen:Customize>
DisplayPreferences>RangeControls
Additionalfunctionalityoftheradarapplication
includes:
•Colorpalettes.
•AddingAISoverlay.
•MARPAtargets.
•VRM/EBLmarkers
Typically,yourvessel’spositionisatthecenterofthe
display,anditsdeadaheadbearingisindicatedbya
verticalheadingline,knownastheShip’sHeading
Marker(SHM).
