Note:IfthecursorisplacedovertheSHM,the
SHMwilltemporarilyberemovedtohelpplacing
markersoracquiringtargetsetc.
On-screentargetsmaybelarge,small,brightorfaint,
dependingonthesizeoftheobject,itsorientation
andsurface.Ifusinganon-HDdigitalradome
scanner,strongesttargetreturnsaredisplayedin
yellowwithweakerreturnsin2shadesofblue.If
usingaHDorSuperHDradarscanner,stronger
targetreturnsshowasdifferentcolorsfromarange
of256colors,providingbetterclarity.Beawarethat
thesizeofatargetonscreenisdependentonmany
factorsandmaynotnecessarilybeproportionaltoits
physicalsize.Nearbyobjectsmayappeartobethe
samesizeasdistantlargerobjects.
Note:Colorsstatedaboverefertothedefault
colorpalette.
Withexperience,theapproximatesizeofdifferent
objectscanbedeterminedbytherelativesizeand
brightnessoftheechoes.
Youshouldbearinmindthatthesizeofeach
on-screentargetisaffectedby:
•Thephysicalsizeofthereectingobject.
•Thematerialfromwhichtheobjectismade.
Metallicsurfacesreectsignalsbetterthan
non-metallicsurfaces.
•Verticalobjectssuchascliffsreectsignalsbetter
thanslopingobjectssuchassandbanks.
•Highcoastlinesandmountainouscoastal
regionscanbeobservedatlongerradarranges.
Therefore,therstsightoflandmaybeamountain
severalmilesinlandfromthecoastline.Although
thecoastlinemaybemuchnearer,itmaynot
appearontheradaruntilthevesseliscloserto
shore.
•Sometargets,suchasbuoysandsmallvessels
difculttodiscern,becausetheydonotpresenta
consistentreectingsurfaceastheybobandtoss
aboutinthewaves.Consequentlytheseechoes
tendtofadeandbrighten,andattimesdisappear
momentarily.
•Buoysandsmallvesselsresembleeachother,but
vesselscanoftenbedistinguishedbytheirmotion.
Note:AGPSreceiverandafastheadingsensor
arerequiredforMARPAoperation,andtoenable
radar/chartoverlay.
Radarcontextmenu
Theradarapplicationincludesacontextmenuwhich
providespositionaldataandmenuitems.
Thecontextmenuprovidesthefollowingpositional
dataforthecursorlocationinrelationtoyourvessel:
•Latitude
•Longitude
•Range
•Bearing
Thecontextmenualsoprovidethefollowingmenu
items:
•AcquireTarget
•PlaceVRM/EBL
•PlaceWaypointAtCursor
•Slewthermalcamera(Onlyavailablewhen
thermalcameraisconnectedandoperating.)
Accessingthecontextmenu
Youcanaccessthecontextmenubyfollowingthe
stepsbelow.
1.Non-touchscreenandHybridT ouchdisplays:
i.Selectingalocation,objectortargeton-screen
andpressingtheOkbutton.
2.HybridTouchandTouchonlydisplays:
i.Selectinganobjectortargeton-screen.
ii.Selectingandholdingonalocationon-screen.
