1.Carefullyliftoneedgeofthescreenprotection
lm,sothatitisaccessibleforremovingwhen
unitinstallationiscomplete.
2.Ensurethememorycardslotdoorisintheopen
position.
3.Orientatethebottom-rightsideofthebezelunder
thelipofthechartcarddoorandplacethebezel
overthefrontofthedisplay,ensuringthatthe
clipsalongthebottomedgeofthebezellatch
intoposition.
D12586-1
4.Ensurethebezeliscorrectlyalignedwiththe
display,asshown.
5.Applyrmbutevenpressuretothebezelalong
the:
i.Outeredges-workfromthesidesupwards
andthenalongthetopedge,toensurethatit
clipssecurelyintoposition.
ii.Inneredges-particularlyalongthechartcard
dooredge,toensurethatthebezelsitsat.
6.CheckthatthePowerbuttonandchartcarddoor
arefreetooperate.
Removingthefrontbezel
Beforeproceedingensurethememorycardslotdoor
isopen.
D
12584-1
0
1
1
2222
1
2
1
2
1
2
1
2
Important:Usecarewhenremovingthebezel.
Donotuseanytoolstoleverthebezel;doingso
maycausedamage.
1.Placebothyourthumbsontheupperleftedge
ofthedisplay,atthepositionsindicatedinthe
diagramabove.
2.Placeyourngersunderneaththebezel,atthe
positionsindicatedinthediagramabove.
3.Inasinglermmotion,applypressuretothe
outeredgeofthedisplaywithyourthumbsand
pullthebezeltowardsyouusingyourngers.
Thebezelshouldnowcomeawayfromthedisplay
easily.
