LNS TRYTON 112 - CHARACTERISTICS

2 - 2 CHAPTER 2: TECHNICAL DATA
TRYTON 112 CNC
1. CHARACTERISTICS
Depending on the country and the standards in effect, certain technical data, such as the
power supply, may vary. Please see the technical card delivered with the device.
According to the lathe or screw-cutting machine to be equipped, the Tryton 112 bar-
feeder can be supplied in various configurations and models. Some features of the
devices vary according to the model.
Please refer to the data sheet of your Tryton 112 to see which model it is.
Tryton 112 CNC 3 meters 12' 4 meters
Weight 600 Kg (1360 lbs) 700 Kg (1587 lbs) 770 Kg (1745 lbs)
Overall length 4863 mm (191.5") 5373 mm (211.5") 5863 mm (230.8")
Overall width 490 mm (19.3") 490 mm (19.3") 490 mm (19.3")
Height 1060 - 1470 mm
(41.7" - 57,9")
1060 - 1470 mm
(41.7" - 57,9")
1060 - 1470 mm
(41.7" - 57,9")
Centerline range 840 - 1250 mm
(33" - 49,2")
840 - 1250 mm
(33" - 49,2")
840 - 1250 mm
(33" - 49,2")
Loading arm (option) 450 mm (17,7") 450 mm (17,7") 450 mm (17,7")
Maximum bar stock length 3 200 mm (126") 3 710 mm (151,6") 4 200 mm (165,4")
Minimum remnant length 80 mm (3,1") 80 mm (3,1") 80 mm (3,1")
Maximum remnant length 230 mm (9") 230 mm (9") 230 mm (9")
Air pressure 5 Bar (75 Psi) 5 Bar (75 Psi) 5 Bar (75 Psi)
Main electrical power (Volts) 3 x 220 - 480
50 Hz - 60 Hz
3 x 220 - 480
50 Hz - 60 Hz
3 x 220 - 480
50 Hz - 60 Hz
Hydraulic oil ISO 100/25 liters ISO 100/25 liters ISO 100/25 liters
Barrel 5mm
(0,197")
7mm
(0,276")
10mm
(0,394")
12.7mm
(0,5")
Minimum diameter (round) 1 mm
(0,039")
1 mm
(0,039")
3 mm
(0,118")
4 mm
(0,157")
Maximum diameter (round) 5 mm
(0,197")
7 mm
(0,276")
10 mm
(0,394")
12.7 mm
(0,5")
Number of guidance tubes 45 36 24 24
Some measurements can vary according to the type of feeder.
