CHAPTER 5 : PNEUMATICS 5 - 3
TRYTON 112 CNC
1.2 Layout of the pneumatic elements (*)
Designation Article No Description
A 3.471 Air filtering unit
B 3.451 Valve assembly
C 3.434 Pneumatic positioning stop screw
D 3.432 Pneumatic barrel-lock screw
E 3.419 Pneumatic cable-feed clutch screw
