CHAPTER 1 : BASIC NOTIONS 1 - 3
TRYTON 112 CNC
Note :
Example
1.3 Symbols and terminology
This sign recommends following the directions very closely
avoiding causing an incident that could result in injury, damage to
the equipment, or data loss.
This sign indicates that safety measures must be taken to avoid
possible electrical shocks or mishaps.
Note Located in the margin on the left side of the page, the notes stress
interesting points or comments, and provide useful advice for
optimal system operation.
Conditions : Indicates what conditions must be met to conduct the desired
operation.
Used in sequential diagrams, this sign indicates that the required
function has been accomplished.
Used in sequential diagrams, this sign indicates that the required
function has not been accomplished.
